Digital Indicators

We carry a full line of digital weigh indicators from many different manufacturers.

Features:

• ABS plastic dry-use
• Parts counting mode
• Lb, oz, lb:oz, g or kg
• 100 hour internal rechargeable battery
• Backlit LCD display
• 20,000d maximum resolution
• Drives four 350O load cells

Defender™ Series Literature PDF

Features:

• Stainless steel IP66/NEMA4X wash down housings
• Parts counting mode
• Lb, oz, lb:oz, g or kg
• 100 hour internal rechargeable battery
• Backlit LCD display
• 20,000d maximum resolution
• Drives four 350O load cells
• Mounting bracket included

Defender™ Series Literature PDF

Ideal for floor and bench scales, the 204 digital indicator features a large one” high liquid crystal display for high visibility. Selectable weight units, along with gross, tare and net functions, allow the 204 to be an indicator for many applications. Whether you require a permanent installation or a portable scale on the move, the 204 can be powered three ways.

Tailor the 204 to suit your needs with a bi-directional serial port, a custom label/ticket format, auto shut-off and sleep modes to conserve battery power. The 204 is enclosed in stainless steel.

The 204 is furnished complete with motion detection and a serial printer port that allows a print out of weigh data. They are suitable for desk or wall mount and can be adjusted to any angle for easy viewing with its large, 1" high, 6-digit, liquid crystal display.

204 Literature PDF

The 205 can be paired with bench scales, heavy-duty floor scales, or even motor truck scales. State-of-the-art flash technology is employed which allows the indicator's program to be updated on-site. Dual serial ports provide easy connectivity to a remote display, label printer, ticket printer, or PC.

The stainless steel NEMA 4X/IP66 enclosure on the 205 ensures accurate, reliable operation in harsh environments and wash down applications. The easy to view display, with bright red LED segments, displays weight to six digits.

205 Literature PDF

The 210 packs a punch with its ruggedness and extreme versatility. It's ideal for a wide range of weighing needs; whether it’s paired with bench scales, heavy-duty floor scales, or even motor truck scales.

State-of-the-art flash technology is employed which allows the indicator's program to be updated on-site. Dual serial ports provide easy connectivity to a remote display, label printer, ticket printer, or PC.

The stainless steel NEMA 4X/IP66 enclosure on the 210 ensures accurate, reliable operation in harsh environments and wash down applications. The easy to view display, with bright red LED segments, displays weight to six digits.

Kg, lb, tonnes, plus four other weight units, along with a power supply that can operate from 90 to 260 VAC, make the 210 indicators ready for the world!

210 Literature PDF

The compact size of this highly functional weight indicator is a plus for crowded industrial areas. Choose the 390-DC with standard five-key operation or the 590-DC with a complete keypad for easy configuration and calibration. Both models operate on either battery or AC power and provide the flexibility of a counting mode.

• NEMA 4X/IP66–rated stainless steel enclosure
• Large 1" (24.5 mm), six–digit liquid crystal display (LCD)
• 6–button operation
• Power for four 350 ohm load cells or eight 700 ohm load cells
• Configurable units multiplier
• Supports 4– and 6–wire load cell connections
• EDP port for full duplex, RS–232 communications
• Powered by 6 “C” cell alkaline batteries for complete portability (batteries not included)
• AC adapter for 115 or 230 VAC power
• Configurable standby mode that saves battery life
• RATTLETRAP® three–stage digital filtering
• Piece count mode

IQ 390/590 Literature PDF

Rice Lake®'s 420 Plus basic weight indicator offers the added benefit of two internal set points and a full front keypad for simple calibration and configuration. Like our programmable indicators, the 420 Plus offers analog output and will also power as many as eight 350ohm load cells or sixteen 700ohm load cells.

• Large .8” (20.3 mm) Light Emitting Diode (LED) Display
• Full numeric keypad
• NEMA 4X/IP66 stainless steel wash down enclosure
• Power for eight 350ohm load cells or sixteen 700 ohm load cells
• Configurable analog to digital measurement rate
• Primary/secondary units configuration: lb, kg, oz, short tonnes, metric tonnes, g, or none
• Two independent communication ports: (2) full duplex, (1) unidirectional active 20 mA current loop
• Standardized EDP command sets
• Programmable ticket formats up to three 300-character printouts
• Full front-panel digital calibration and configuration
• Universal mounting stand
• Three-stage digital filtering
• Consecutive transaction numbering
• Two digital inputs, two digital outputs
• Time and date (volatile)
• Count mode

420 Literature PDF

The 720i from Rice Lake® is an affordable path to gaining the function and ability of our more advanced intelligent indicators. From basic weighing and data collection to recipe formulation, inventory management and traceability, choose Rice Lake®'s 720i. Advanced programmability using ProAction (PCEE) and enhanced data base storage make the 720i ideal for a wide variety of weighing applications. Available in both universal and panel-mount configurations.

• LCD display size: panel mount (3.8" x 1.2") universal (5.3" x 1.5")
• Four soft keys
• Truck in/out, 1,000-ID memory
• Process control engine - define conditions and actions
• Data storage onboard, user-defined
• (8) Digital I/O (expandable)
• One option slot for pluggable options
• (20) Auxiliary print formats
• Time and date
• Audit trail tracking and alibi storage
• Peak hold
• Rate of change
• Multi-range/interval
• Local/remote

Functionality:

• Two full duplex serial ports
• One PC style (PS/2) keyboard port
• Header for fiber optic, Ethernet or USB

720 Literature PDF

Rice Lake®'s well-rounded indicator selection is led by the impressive and adaptable 920i, delivering more features, more programmability, and more power for your process. The 920i combines performance-driven circuitry, simplified architecture, and customized display features to take your system further. Choose from our universal, panel mount, or wall-mount style.

Up to ten different screens can be programmed to change with any given process, while graphic icons and messages show set point and function status. The multi-channel display feature shows the weight on an individual scale or a combination of totalized scales. When used in batching/mixing applications, one 920i is capable of handling multiple scale, flow temperature and pulse. It can control hundreds of I/O set points, queuing such things as gates and conveyors. The 920i's complete database capability stores your important data and files.

• Large (4.6" W x 3.4" H, 320 x 240 pixel) back-lit LCD graphical display
• Selectable character sizes from .25" to 1.2"
• 60 configurable operator prompts
• Display up to four scale channels per screen with required legal for trade information
• 32 scale accumulators
• Five soft keys with 10 user-defined, 14 pre-set functions per screen
• 10 programmable display screens
• Millivolt calibration, 5-point linearization and geographical calibration
• NEMA 4X/IP66 stainless steel enclosure
• Selectable A/D measurement rate up to 960/second
• 100 set points, 30 configurable set point types
• Two slots for option cards
• 1,000-ID truck register for in/out weighing
• 64K user on-board NV RAM
• User programmable 1024K flash memory
• Reflash memory to upgrade firmware
• Power for 16 350ohm load cells per A/D board

920 Literature PDF

The 805TS digital indicator is a general purpose weight indicator having high accuracy, high reliability, anti-jamming and multi-functions with source of signal coming from load cells, which adopted the A/D conversion technology of 24-bit microprocessor and the rate of conversion is up to 200 per second. The indicator is suitable for measuring seafood, food, medicament and field factory. It is also a perfect choice for platform scales and baggage scales.

805 Literature PDF

Rice Lake’s Legend Series combines industrial strength with innovative features to deliver the best in performance and value.

Features:

• Two serial ports
• Single scale input from light capacity bench scales to heavy capacity industrial scales
• Local/remote

Rice Lake® 480 Literature PDF

Features:

• NTEP approved at 5,000 divisions C.O.C.# 09-070
• Runs continuous on A/C adaptor or approximate 10hrs on 6volt internal rechargeable battery
• Auto Shutoff
• Full Duplex RS-232 Serial Port displays up to 50,000 graduations
• Mild Steel NEMA 12 enclosure
